Showing 265–276 of 472 results

Buy/Sell Used 55L Rubber Compound Dispersion Kneader Machine

Model		VAT-3/40	VAT-10/40	VAT-20/40	VAT-35/30	VAT-55/30	VAT-75/30	VAT-110/30
Total volume of mixing chamber (L)		8	25	45	75	125	170	250
Working volume of mixing chamber (L)		3	10	20	35	55	75	110
Speed of rotor (front/rear) (r/min)		40/31	40/31	40/31	30/24.5	30/24.5	30/24.5	30/25
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (kw)		7.5	22	37	55	75	110	185
Turning motor power (kw)		0.55	1.1	1.5	1.5	2.2	4	4
Turning angle (°)		140	140	140	140	140	140	140
Overall dimension (mm)	(L)	1670	2300	2360	3240	3400	3860	4225
	(W)	950	1350	1750	2080	2300	2300	1980
	(H)	1880	2120	2430	2650	3100	3375	3180
Weight (T)		1.2	2.3	4.5	6.5	7.5	10	11

Buy/Sell Used 6-Inch 2kg Two Roll Rubber Mixing Mill Machine

Model		VAT-250	VAT-300	VAT-360	VAT-400	VAT-450	VAT-550	VAT-560	VAT-610	VAT-660	VAT-660(R)	VAT-710	VAT-760	VAT-810
Diameter of rolls(mm)		250	300	360	400	450	550	560	610	660	660	710	760	810
Working length of rolls(mm)		620	760	900	1000	1200	1530	1530	1830	2130	2130	2200	2540	2540
Linear speed of front roll(m/min)		15.2	14.5	16.26	18.65	23.85	27.18	27.61	28.7	32.45	28.6	31.9	33.23	31.9
Roll Friction Ratio		1:1.10	1:1.10	1:1.25	1:1.27	1:1.27	1:1.25	1:1.25	1:1.25	1:1.09	1:1.24	1:1.09	1:1.09	1:1.09
Batch Capacity		10-15	14-16	15-20	25-35	30-50	50-60	50-60	90-120	165	165	350	350	350
Motor Power		18.5	22	30	40	55	110	110	160	185	250	280	315	355
Max. Nip(mm)		8	8	10	10	10	15	15	15	15	15	15	15	15
Overall dimension(mm)	L	3220	3570	3920	4380	5050	6040	6040	6750	7040	7465	7650	8560	8680
	W	1500	1400	1650	1710	1920	2100	2100	3040	3660	3660	3200	2970	3575
	H	1290	1350	1725	1880	1870	1625	1625	1743	2080	2080	2860	1970	3020
Weight(ton)		3.8	4.5	6	8	13	22	22	35	45	45	50	58	68

Add to wishlist

Quick view

Add to compare

Buy/Sell Used 75L Rubber Kneader Machine with PLC Control

Model		VAT-3/40	VAT-10/40	VAT-20/40	VAT-35/30	VAT-55/30	VAT-75/30	VAT-110/30
Total volume of mixing chamber (L)		8	25	45	75	125	170	250
Working volume of mixing chamber (L)		3	10	20	35	55	75	110
Speed of rotor (front/rear) (r/min)		40/31	40/31	40/31	30/24.5	30/24.5	30/24.5	30/25
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (kw)		7.5	22	37	55	75	110	185
Turning motor power (kw)		0.55	1.1	1.5	1.5	2.2	4	4
Turning angle (°)		140	140	140	140	140	140	140
Overall dimension (mm)	(L)	1670	2300	2360	3240	3400	3860	4225
	(W)	950	1350	1750	2080	2300	2300	1980
	(H)	1880	2120	2430	2650	3100	3375	3180
Weight (T)		1.2	2.3	4.5	6.5	7.5	10	11

Buy/Sell Used EPDM NBR Rubber Dispersion Kneader 55 Ltr

Model		VAT-3/40	VAT-10/40	VAT-20/40	VAT-35/30	VAT-55/30	VAT-75/30	VAT-110/30
Total volume of mixing chamber (L)		8	25	45	75	125	170	250
Working volume of mixing chamber (L)		3	10	20	35	55	75	110
Speed of rotor (front/rear) (r/min)		40/31	40/31	40/31	30/24.5	30/24.5	30/24.5	30/25
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (kw)		7.5	22	37	55	75	110	185
Turning motor power (kw)		0.55	1.1	1.5	1.5	2.2	4	4
Turning angle (°)		140	140	140	140	140	140	140
Overall dimension (mm)	(L)	1670	2300	2360	3240	3400	3860	4225
	(W)	950	1350	1750	2080	2300	2300	1980
	(H)	1880	2120	2430	2650	3100	3375	3180
Weight (T)		1.2	2.3	4.5	6.5	7.5	10	11

Buy/Sell Used Plasticizing Rubber Kneader & 18-Inch Mixing Mill

Model		VAT-250	VAT-300	VAT-360	VAT-400	VAT-450	VAT-550	VAT-560	VAT-610	VAT-660	VAT-660(R)	VAT-710	VAT-760	VAT-810
Diameter of rolls(mm)		250	300	360	400	450	550	560	610	660	660	710	760	810
Working length of rolls(mm)		620	760	900	1000	1200	1530	1530	1830	2130	2130	2200	2540	2540
Linear speed of front roll(m/min)		15.2	14.5	16.26	18.65	23.85	27.18	27.61	28.7	32.45	28.6	31.9	33.23	31.9
Roll Friction Ratio		1:1.10	1:1.10	1:1.25	1:1.27	1:1.27	1:1.25	1:1.25	1:1.25	1:1.09	1:1.24	1:1.09	1:1.09	1:1.09
Batch Capacity		10-15	14-16	15-20	25-35	30-50	50-60	50-60	90-120	165	165	350	350	350
Motor Power		18.5	22	30	40	55	110	110	160	185	250	280	315	355
Max. Nip(mm)		8	8	10	10	10	15	15	15	15	15	15	15	15
Overall dimension(mm)	L	3220	3570	3920	4380	5050	6040	6040	6750	7040	7465	7650	8560	8680
	W	1500	1400	1650	1710	1920	2100	2100	3040	3660	3660	3200	2970	3575
	H	1290	1350	1725	1880	1870	1625	1625	1743	2080	2080	2860	1970	3020
Weight(ton)		3.8	4.5	6	8	13	22	22	35	45	45	50	58	68

Buy/Sell Used Rubber Mixing Mill | Hot Sale Two-Roller Machine 450 X 1200 mm

Model		VAT-250	VAT-300	VAT-360	VAT-400	VAT-450	VAT-550	VAT-560	VAT-610	VAT-660	VAT-660(R)	VAT-710	VAT-760	VAT-810
Diameter of rolls(mm)		250	300	360	400	450	550	560	610	660	660	710	760	810
Working length of rolls(mm)		620	760	900	1000	1200	1530	1530	1830	2130	2130	2200	2540	2540
Linear speed of front roll(m/min)		15.2	14.5	16.26	18.65	23.85	27.18	27.61	28.7	32.45	28.6	31.9	33.23	31.9
Roll Friction Ratio		1:1.10	1:1.10	1:1.25	1:1.27	1:1.27	1:1.25	1:1.25	1:1.25	1:1.09	1:1.24	1:1.09	1:1.09	1:1.09
Batch Capacity		10-15	14-16	15-20	25-35	30-50	50-60	50-60	90-120	165	165	350	350	350
Motor Power		18.5	22	30	40	55	110	110	160	185	250	280	315	355
Max. Nip(mm)		8	8	10	10	10	15	15	15	15	15	15	15	15
Overall dimension(mm)	L	3220	3570	3920	4380	5050	6040	6040	6750	7040	7465	7650	8560	8680
	W	1500	1400	1650	1710	1920	2100	2100	3040	3660	3660	3200	2970	3575
	H	1290	1350	1725	1880	1870	1625	1625	1743	2080	2080	2860	1970	3020
Weight(ton)		3.8	4.5	6	8	13	22	22	35	45	45	50	58	68

Buy/Sell Used Uni Drive Rubber Mixing Mill | Two Roll Open Mill 400V

Model		VAT-250	VAT-300	VAT-360	VAT-400	VAT-450	VAT-550	VAT-560	VAT-610	VAT-660	VAT-660(R)	VAT-710	VAT-760	VAT-810
Diameter of rolls(mm)		250	300	360	400	450	550	560	610	660	660	710	760	810
Working length of rolls(mm)		620	760	900	1000	1200	1530	1530	1830	2130	2130	2200	2540	2540
Linear speed of front roll(m/min)		15.2	14.5	16.26	18.65	23.85	27.18	27.61	28.7	32.45	28.6	31.9	33.23	31.9
Roll Friction Ratio		1:1.10	1:1.10	1:1.25	1:1.27	1:1.27	1:1.25	1:1.25	1:1.25	1:1.09	1:1.24	1:1.09	1:1.09	1:1.09
Batch Capacity		10-15	14-16	15-20	25-35	30-50	50-60	50-60	90-120	165	165	350	350	350
Motor Power		18.5	22	30	40	55	110	110	160	185	250	280	315	355
Max. Nip(mm)		8	8	10	10	10	15	15	15	15	15	15	15	15
Overall dimension(mm)	L	3220	3570	3920	4380	5050	6040	6040	6750	7040	7465	7650	8560	8680
	W	1500	1400	1650	1710	1920	2100	2100	3040	3660	3660	3200	2970	3575
	H	1290	1350	1725	1880	1870	1625	1625	1743	2080	2080	2860	1970	3020
Weight(ton)		3.8	4.5	6	8	13	22	22	35	45	45	50	58	68

Add to wishlist

Quick view

Add to compare

Buy| Sell Used Rubber Dispersion Kneader

Make:- Manjeet Singh

Motor :- 135 hp

Tilting:- Screw Tilting

Complete with Panel Cabinet

Add to wishlist

Quick view

Buy| Sell Used Second-Hand Rubber Dispersion Kneader 75L

Add to compare

Buy| Sell Used Rubber Dispersion Kneader 75L

Introducing the Cutting-Edge Rubber Dispersion Kneader 75L:Revolutionize your rubber processing with the innovative Rubber Dispersion Kneader 75L, a pinnacle of efficiency, reliability, and precision in the rubber manufacturing industry. Engineered for excellence, this advanced kneading machine is designed to elevate your production processes, ensuring exceptional quality and consistency in rubber dispersion.Features:

High Capacity: With a volumetric capacity of 75 liters, this kneader accommodates substantial quantities of rubber compounds, optimizing production output without compromising on quality.
Precision Kneading: The machine boasts a robust mixing chamber equipped with cutting-edge technology that ensures thorough dispersion and uniformity of rubber compounds. Its precision mixing action guarantees homogeneity, minimizing batch-to-batch variations.
Efficient Cooling System: A superior cooling system maintains the optimal temperature during the kneading process, preventing overheating and ensuring the integrity of the rubber compounds.
User-Friendly Interface: The intuitive control panel simplifies operation, allowing for easy adjustments and precise control over mixing parameters. Operators can effortlessly monitor and adjust settings for the desired rubber compound characteristics.
Durable Construction: Crafted from high-quality materials and built to withstand rigorous industrial use, the Rubber Dispersion Kneader 75L promises durability and longevity, reducing maintenance requirements and downtime.

Benefits:

Enhanced Productivity: Increase your production efficiency with this high-capacity kneader, reducing processing time and enhancing overall output.
Consistent Quality: Achieve unparalleled consistency in rubber compounds, meeting the most stringent quality standards with every batch.
Versatility: Suitable for a wide range of rubber formulations and applications, catering to diverse industry needs.
Reliable Performance: Experience reliable and precise mixing, ensuring uniform dispersion and superior product quality.

Applications:This kneader finds application across various industries, including rubber manufacturing for automotive components, industrial seals, rubber sheets, and a multitude of other rubber-based products.Conclusion:The Rubber Dispersion Kneader 75L stands as a testament to cutting-edge engineering, offering unparalleled efficiency, precision, and reliability in the realm of rubber processing. Elevate your production capabilities and achieve unmatched quality with this state-of-the-art kneading solution. Experience seamless operations and superior results with every batch, making it an indispensable asset for your manufacturing endeavors.

Add to wishlist

Quick view

Add to compare

Buy| Sell Used Rubber kneader Machine

Buy| Sell Used Rubber kneader Machine Size :- 55 ltr Make:- Verma machinery Motor:- 75 hp Motor Make:- Crompton Greaves Condition:-Good running condition

Add to wishlist

Quick view

Add to compare

Buy| Sell Used Rubber Mixing Mill

Introducing our high-quality, pre-owned Rubber Mixing Mill, meticulously designed to meet the demands of the rubber processing industry. This robust and reliable equipment is an exceptional addition to any manufacturing facility, offering unparalleled efficiency and precision in the blending and refining of rubber compounds.Key Features:

Durable Construction: Crafted from premium-grade materials, this used mixing mill ensures longevity and dependable performance, even after extensive use.
Versatile Mixing Capabilities: Engineered with precision, it facilitates the thorough mixing and dispersion of rubber compounds, additives, and pigments, enhancing product consistency and quality.
Efficient Processing: Equipped with advanced controls and mechanisms, this machine streamlines the blending process, reducing operational time and maximizing productivity.
Customizable Operations: The adjustable settings and controls allow operators to fine-tune the mixing parameters, ensuring tailored outcomes to meet specific production requirements.
Safety Features: Engineered with safety in mind, this mixing mill comes with built-in safety measures to protect operators during operation, minimizing risks and ensuring a secure working environment.
Cost-Effective Solution: Investing in a quality, pre-owned mixing mill offers a cost-effective alternative without compromising on performance or reliability, providing excellent value for your business.

Whether you're in the rubber, plastic, or chemical industry, this used Rubber Mixing Mill presents an incredible opportunity to enhance your production capabilities. It has undergone rigorous inspections and maintenance checks to guarantee optimal functionality and performance.This equipment stands as a testament to durability, efficiency, and precision in rubber processing, making it an ideal choice for businesses seeking a reliable solution for their mixing needs.

Add to wishlist

Quick view

Add to compare

Buy| Sell Used Rubber Molding Hydraulic Press Pillar Type PLC Automated – 40”x40”

Buy| Sell Used Rubber Molding Hydraulic Press Pillar Type PLC Automated - 40”x40”Type:- Up Stroke Single Acting 4 Pillar Type Model No.:- MRMPL- 830 Platen Size:- 40"X40" Capacity:- 830 Ton Ram Dia:- 700 Ram Stroke:- 500mm No. of Daylight:- 02 Daylight Gap:- 300mm Platen Heating Plate:- Electrical Hydraulic Working Pressure:- 210kg/cm2 Hydraulic Power Pack:- 20HP Main Ram Cylinder 2.0 HP- Top Ejector 2.0HP- Heat Exchanger
