Showing 445–456 of 552 results

Buy 16x42 Rubber Mixing Mill Uni-Drive 60 HP Motor

Second-Hand 16×42 Rubber Mixing Mill Uni-Drive 60 HP Motor

Model		VAT-250	VAT-300	VAT-360	VAT-400	VAT-450	VAT-550	VAT-610	VAT-660	VAT-660(R)	VAT-710	VAT-760	VAT-810
Diameter of rolls(mm)		250	300	360	400	450	550	610	660	660	710	760	810
Working length of rolls(mm)		620	760	900	1000	1200	1530	1830	2130	2130	2200	2540	2540
Linear speed of front roll(m/min)		15.2	14.5	16.26	18.65	23.85	27.18	28.7	32.45	28.6	31.9	33.23	31.9
Roll Friction Ratio		1:1.10	1:1.10	1:1.25	1:1.27	1:1.27	1:1.25	1:1.25	1:1.09	1:1.24	1:1.09	1:1.09	1:1.09
Batch Capacity		10-15	14-16	15-20	25-35	30-50	50-60	90-120	165	165	350	350	350
Motor Power		18.5	22	30	40	55	110	160	185	250	280	315	355
Max. Nip(mm)		8	8	10	10	10	15	15	15	15	15	15	15
Overall dimension(mm)	L	3220	3570	3920	4380	5050	6040	6750	7040	7465	7650	8560	8680
	W	1500	1400	1650	1710	1920	2100	3040	3660	3660	3200	2970	3575
	H	1290	1350	1725	1880	1870	1625	1743	2080	2080	2860	1970	3020
Weight(ton)		3.8	4.5	6	8	13	22	35	45	45	50	58	68

Second-Hand 2 Ltr Rubber Internal Mixer – Lab Model

Model		VAT-45E	VAT-90E	VAT-135E	VAT160E	VAT-190E
Total volume of mixing chamber (L)		45	90	135	160	190
Working volume of mixing chamber (L)		30	56	90	104	125
Speed of rear rotor (r/min)		6-60	5-50	6-60	5-50	6-60
Rotor speed ratio		1:1	1:1	1:1	1:1	1:1
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (kw)		280	450	720	750	1100
Overall dimension (mm)	(L)	6200	7400	8200	8600	9000
	(W)	2500	2880	2950	3000	4000
	(H)	3750	4700	5375	6000	6220
Weight (T)		15	23	29	39	45

Second-Hand 75L Kneader with 75 HP Motor and Complete Panel

Capacity: 75 liters
Motor Power: 75 HP
Condition: Second-hand, excellent working order
Panel: Complete control panel included
Application: Rubber mixing and processing
Build: Heavy-duty structure for long life
Usage: Suitable for industrial rubber production
Location: Available in India

Add to wishlist

Quick view

Add to compare

Secondhand 12×30 Rubber Mixing Mill Machine

The demand for quality rubber products continues to grow across industries such as automotive, footwear, industrial goods, and rubber component

Secondhand 250 mm Rubber Filter Extruder / Reclaim Strainer

This serves the rubber processing and recycling industries. The rubber compound is supposed to be filtered and purified to maintain

Secondhand 25L Rubber Kneader – 40 HP Motor Unit

Model		VAT-3/40	VAT-10/40	VAT-20/40	VAT-35/30	VAT-55/30	VAT-75/30	VAT-110/30
Total volume of mixing chamber (L)		8	25	45	75	125	170	250
Working volume of mixing chamber (L)		3	10	20	35	55	75	110
Speed of rotor (front/rear) (r/min)		40/31	40/31	40/31	30/24.5	30/24.5	30/24.5	30/25
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (kw)		7.5	22	37	55	75	110	185
Turning motor power (kw)		0.55	1.1	1.5	1.5	2.2	4	4
Turning angle (°)		140	140	140	140	140	140	140
Overall dimension (mm)	(L)	1670	2300	2360	3240	3400	3860	4225
	(W)	950	1350	1750	2080	2300	2300	1980
	(H)	1880	2120	2430	2650	3100	3375	3180
Weight (T)		1.2	2.3	4.5	6.5	7.5	10	11

Secondhand 30rpm 75KG/H Two-Wing Rotor Rubber Kneader Machine

Model		VAT-3/40	VAT-10/40	VAT-20/40	VAT-35/30	VAT-55/30	VAT-75/30	VAT-110/30
Total volume of mixing chamber (L)		8	25	45	75	125	170	250
Working volume of mixing chamber (L)		3	10	20	35	55	75	110
Speed of rotor (front/rear) (r/min)		40/31	40/31	40/31	30/24.5	30/24.5	30/24.5	30/25
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (kw)		7.5	22	37	55	75	110	185
Turning motor power (kw)		0.55	1.1	1.5	1.5	2.2	4	4
Turning angle (°)		140	140	140	140	140	140	140
Overall dimension (mm)	(L)	1670	2300	2360	3240	3400	3860	4225
	(W)	950	1350	1750	2080	2300	2300	1980
	(H)	1880	2120	2430	2650	3100	3375	3180
Weight (T)		1.2	2.3	4.5	6.5	7.5	10	11

Secondhand 32rpm 75L EPDM Rubber Kneader Machine with Motor Drive

Model		VAT-3/40	VAT-10/40	VAT-20/40	VAT-35/30	VAT-55/30	VAT-75/30	VAT-110/30
Total volume of mixing chamber (L)		8	25	45	75	125	170	250
Working volume of mixing chamber (L)		3	10	20	35	55	75	110
Speed of rotor (front/rear) (r/min)		40/31	40/31	40/31	30/24.5	30/24.5	30/24.5	30/25
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (kw)		7.5	22	37	55	75	110	185
Turning motor power (kw)		0.55	1.1	1.5	1.5	2.2	4	4
Turning angle (°)		140	140	140	140	140	140	140
Overall dimension (mm)	(L)	1670	2300	2360	3240	3400	3860	4225
	(W)	950	1350	1750	2080	2300	2300	1980
	(H)	1880	2120	2430	2650	3100	3375	3180
Weight (T)		1.2	2.3	4.5	6.5	7.5	10	11

Secondhand 35L Rubber Kneader – Affordable & High-Quality

Model		VAT-3/40	VAT-10/40	VAT-20/40	VAT-35/30	VAT-55/30	VAT-75/30	VAT-110/30
Total volume of mixing chamber (L)		8	25	45	75	125	170	250
Working volume of mixing chamber (L)		3	10	20	35	55	75	110
Speed of rotor (front/rear) (r/min)		40/31	40/31	40/31	30/24.5	30/24.5	30/24.5	30/25
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (kw)		7.5	22	37	55	75	110	185
Turning motor power (kw)		0.55	1.1	1.5	1.5	2.2	4	4
Turning angle (°)		140	140	140	140	140	140	140
Overall dimension (mm)	(L)	1670	2300	2360	3240	3400	3860	4225
	(W)	950	1350	1750	2080	2300	2300	1980
	(H)	1880	2120	2430	2650	3100	3375	3180
Weight (T)		1.2	2.3	4.5	6.5	7.5	10	11

Secondhand 4 Roll Rubber Calender Machine | Size 28×72 | Vatsn Tecnic

Parameter/model		VAT-4-230	VAT-4-360	VAT-4-400	VAT-4-450	VAT-4-550	VAT-4-610	VAT-4-810
Roll diameter (mm)		230	360	400	450	550	610	810
Roll working length (mm)		630	1120	1200	1400	1500	1730	2500
Ratio of rubber speed		1:1:1:1	0.7:1:1:0.7	1:1.4:1.4:1	1:1.5:1.5:1	1:1.5:1.5:1	1:1.4:1.4:1	1:1.4:1.4:1
Roll speed (m/min)		2.1-21	2-20.1	3-26	2.5-25	3-30	8-50	4-40
Nip adjust range (mm)		0-10	0-10	0-10	0-10	0-15	0-10	0-10
Motor power (KW)		15	55	75	110	160	185	132x4
Size (mm)	Length	2800	3300	6400	6620	7550	7880	11400
Width		930	1040	1620	1970	2400	2560	3900
Height		1890	2350	2490	2740	3400	3920	5140
Weight (KG)		5000	16000	20000	23000	45000	50000	130000

Secondhand 4.5-inch Hot Feed Rubber Extruder with 30 HP

MODEL		Vatsn-1	Vatsn-2	Vatsn-3	Vatsn-4	Vatsn-5	Vatsn-6	Vatsn-8	Vatsn-9
Scroll Size	Inches	2	3	4	4.5	5	6	8	10
Scroll Size	m.m.	50	75	100	115	125	150	200	250
Scroll Speed	RPM	38	38	38	38	38	38	38	38
L/D Ratio		4:1 TO 6:1
Motor	H.P	7.5	10	15	20	25	40	60	100
Reduction Gear Ratio		25:01:00	25:01:00	25:01:00	25:01:00	25:01:00	25:01:00	25:01:00	25:01:00
Feed Roller		Not Available		Optional
Extruder Head		Standard Adaptors other heads as per customer requirement(optional)
Barrel Heating/Cooling		Jacketed type in single zone for efficient heating /cooling
Water Cooling Requirement	LPM	10	15	20	30	40	80	150	180

Add to wishlist

Quick view

Add to compare

Secondhand 45L High-Capacity Intermix Mixing Machine

Secondhand 45L High-Capacity Intermix Mixing Machine – Reliable Industrial Solution Secondhand 45L High-Capacity Intermix Mixing Machine for Cost-Effective Rubber Processing
