Compression MoldingShop
Used Steel Cord Conveyor Belt Line 1800x10000mm For Sale
| Parameter | unit | VAT-1800X12000*2 | VAT-1800X10000*2 | VAT-1600X10000*2 | VAT-1600X10000*1 | VAT-1400X10000*1 |
| Hot-plate size | mm | 1800*12000 | 1800*1000 | 1600*10000 | 1600*10000 | 1400*10000 |
| Total pressure | mn | 74 | 72 | 56 | 64 | 49 |
| Hot-plate unit pressure | mpa | 3.4 | 4 | 3.5 | 4 | 3.5 |
| Plunger diameter | mm | 500 | 500 | 450 | 500 | 450 |
| Plunger No | 18 | 18 | 18 | 18 | 18 | |
| Max plunger stroke | mm | 400 | 300 | 400 | 300 | 300 |
| Gripping strength | mn | 1.2 | 1.5 | 1.2 | 1.2 | 0.9 |
| Tension force | mn | 1.101.2 | 1.1 | 1 | 0.5 | 0.9 |
| Steam pressure | mpa | 0.63 | 0.6-0.8 | 0.63 | 0.6-0.8 | 0.63 |
| Cooling water pressure | mpa | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 |
| controlling method | PLC | PLC | PLC | PLC | PLC |
Used Three Roll Calender Machine – 3 Roll (710 x 2500 mm) for Sale
Key Features
Roller Size: 710 mm diameter × 2500 mm width
Machine Type: Secondhand 3-roll calender
Usage: Ideal for rubber & plastic sheet manufacturing
Condition: Well-maintained and ready to use
Performance: Ensures uniform thickness & smooth finish
Durability: Sturdy design for continuous operation
Cost: High performance at a lower price
Used Three Roll Rubber Calendar 10×30, 10 HP Gearbox Price
| Parameter/model | VAT-3-250 | VAT-3-360 | VAT-3-400 | VAT-3-450 | VAT-3-560 | VAT-3-610 | VAT-3-810 | ||
| Roll diameter (mm) | 250 | 360 | 400 | 450 | 560 | 610 | 810 | ||
| Roll working length (mm) | 720 | 1120 | 1200 | 1400 | 1650 | 1730 | 2130 | ||
| Ratio of rubber speed | 1:1 | 1:1 | 1:1 | 1:1.5:1 | 1:1.5:1 | 1:1.4:1 | 1:01:01 | ||
| Roll speed (m/min) | 2-15.9 | 3-20 | 3-26 | 2.6-26.2 | 3-30 | 5.4-54 | 3-30 | ||
| Nip adjust range (mm) | 0-6 | 0-10 | 0-10 | 0-10 | 0-15 | 0.5-25 | 0.2-25 | ||
| Motor power (KW) | 22 | 45 | 55 | 75 | 110 | 160 | 132x3 | ||
| Size (mm) | Length | 3950 | 5400 | 5600 | 7013 | 7200 | 7987 | 8690 | |
| Width | 1110 | 1542 | 1400 | 1595 | 1760 | 1860 | 3139 | ||
| Height | 1810 | 2440 | 2520 | 2900 | 3800 | 3950 | 5050 | ||
| Weight (KG) | 5500 | 14000 | 18000 | 21000 | 35000 | 42000 | 110000 | ||
Used Twin Screw Extruder Rubber Sheeting with Calendar
Key Specifications:
Machine Type: Twin Screw Rubber Sheeting Extruder
Condition: Tested and verified, excellent performance
Capacity: Designed for TSR rubber sheeting production
Motor: Heavy-duty, reliable performance
Warranty: Available on request
Usage: Rubber sheeting, TSR production, compound processing
Location: Available across India – Delhi, Mumbai, Chennai, Bangalore
Used Two Roll Rubber Uni Drive Mixing Mill 14 X 36 Motor 40 Hp
| Model | VAT-250 | VAT-300 | VAT-360 | VAT-400 | VAT-450 | VAT-550 | VAT-560 | VAT-610 | VAT-660 | VAT-660(R) | VAT-710 | VAT-760 | VAT-810 | |
| Diameter of rolls(mm) | 250 | 300 | 360 | 400 | 450 | 550 | 560 | 610 | 660 | 660 | 710 | 760 | 810 | |
| Working length of rolls(mm) | 620 | 760 | 900 | 1000 | 1200 | 1530 | 1530 | 1830 | 2130 | 2130 | 2200 | 2540 | 2540 | |
| Linear speed of front roll(m/min) | 15.2 | 14.5 | 16.26 | 18.65 | 23.85 | 27.18 | 27.61 | 28.7 | 32.45 | 28.6 | 31.9 | 33.23 | 31.9 | |
| Roll Friction Ratio | 1:1.10 | 1:1.10 | 1:1.25 | 1:1.27 | 1:1.27 | 1:1.25 | 1:1.25 | 1:1.25 | 1:1.09 | 1:1.24 | 1:1.09 | 1:1.09 | 1:1.09 | |
| Batch Capacity | 10-15 | 14-16 | 15-20 | 25-35 | 30-50 | 50-60 | 50-60 | 90-120 | 165 | 165 | 350 | 350 | 350 | |
| Motor Power | 18.5 | 22 | 30 | 40 | 55 | 110 | 110 | 160 | 185 | 250 | 280 | 315 | 355 | |
| Max. Nip(mm) | 8 | 8 | 10 | 10 | 10 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | |
Overall dimension(mm) | L | 3220 | 3570 | 3920 | 4380 | 5050 | 6040 | 6040 | 6750 | 7040 | 7465 | 7650 | 8560 | 8680 |
| W | 1500 | 1400 | 1650 | 1710 | 1920 | 2100 | 2100 | 3040 | 3660 | 3660 | 3200 | 2970 | 3575 | |
| H | 1290 | 1350 | 1725 | 1880 | 1870 | 1625 | 1625 | 1743 | 2080 | 2080 | 2860 | 1970 | 3020 | |
| Weight(ton) | 3.8 | 4.5 | 6 | 8 | 13 | 22 | 22 | 35 | 45 | 45 | 50 | 58 | 68 | |
Used XKJ 510 Rubber Refiner Mill – Buy Online
Key Specifications:
Machine Type: Twin Screw Rubber Sheeting Extruder (TSR)
Application: Rubber sheet production and processing
Screw Design: Twin screw with efficient sheeting output
Sheet Width Capacity: 560 – 760 mm (varies with model)
Motor Power: 75 – 110 KW (tested and reliable)
Condition: Used / Pre-owned (tested and verified)
Production Capacity: Medium to large-scale rubber industries
Warranty: Available on refurbished machines
Location: Available across India with delivery support
Used XKP 660 Tyre Recycling Line – Complete Scrap Tyre Setup
| Model | VAT-360 | VAT-400 | VAT-450 | VAT-550 | VAT-560 | VAT-660 | VAT-710 | |
| Diameter of rolls(mm) | 360 | 400 | 450 | 550 | 560-510 | 660 | 710 | |
| Working length of rolls(mm) | 900 | 1000 | 1200 | 1500 | 1530 | 2130 | 2200 | |
| Linear speed of front roll(r/min) | 16.25 | 18.65 | 21.8 | 22.5 | 27.2 | 28 | 31.9 | |
| Speed ratio of front & rear roll | 01:01.3 | 01:01.3 | 01:01.3 | 01:01.2 | 01:01.2 | 01:01.2 | 01:01.5 | |
| Max roll gap(mm) | 10 | 10 | 15 | 16 | 15 | 15 | 15 | |
| Feeding capacity per batch(kg) | 20-25 | 18-35 | 50 | 50-65 | 50-65 | 165 | 190 | |
| Driving motor power(kw) | 30 | 45 | 55 | 110 | 90 | 240 | 280 | |
| Bearing body structure | Roller bearing with grease/thin oil lubrication+square type reducer | |||||||
Overall dimension(mm) | L | 4200 | 4920 | 5405 | 6646 | 6270 | 7280 | 8185 |
| W | 1780 | 1780 | 1740 | 2736 | 2282 | 3400 | 3910 | |
| H | 1760 | 1800 | 1790 | 2105 | 2000 | 2530 | 2270 | |
| Weight(ton) | 6.5 | 7.5 | 12 | 22 | 22.5 | 49 | 51 | |
