Buy | Sell Secondhand Rubber Refiner Mill 480 X 610 X 1200 mm
| Type | VAT-400 | VAT-450 | VAT-480 |
| Working diameter of rolls(mm) | ?400front roller ?480rear roller | ?450front roller ?510rear roller | ?480front roller ?610rear roller |
| Roll casting process | centrifugal composite casting | centrifugal composite casting | centrifugal composite casting |
| Roll cooling mode | Around the borehole cooling | Around the borehole cooling | Around the borehole cooling |
| The surface of the roll material | High nickel chromium molybdenum alloy | High nickel chromium molybdenum alloy | High nickel chromium molybdenum alloy |
| Working length of the roll(mm) | 650 | 800/1000 | 800/1000/1200 |
| After the roller line speed(m/min) | 32.94(optional) | 49/55.2/63.4(optional) | 57.5-75.1(optional) |
| Front and rear roller line speed ratio | 1.27-1.815(optional) | 1.38/1.82/2(optional) | 1.27-1.815(optional) |
| Production capacity(kg/h) | 300 | 360 | 500-800 |
| Motor power(kw) | 55 | 55 | 75/90 |
| Roller spacing adjustment range(mm) | 0.1-15 | 0.1-15 | 0.1-15 |
| Reducer | ZSY hard-tooth face gear | ZSY hard-tooth face gear | ZSY hard-tooth face gear |
| Bearing type | the double spherical roller bearing | the double spherical roller bearing | the double spherical roller bearing |
| Dimensions of LxWxH(mm) | 4750x2300x1835 | 4060x2200x1470 | 5070x2800x1978 |
| Quality(kg) | about10500 | about12800 | about20000 |
Buy Ex-Owned Double Daylight 1500 Ton Hydraulic Press
| MODEL NO. | VAT-75 | VAT-100 | VAT-150 | VAT-200 | VAT-250 | VAT-300 | VAT-350 | VAT-400 | VAT-500 |
| PLATEN SIZE (MM) | 360x360 | 410x410 | 460x460 | 510x510 | 610x610 | 660x660 | 760x760 | 800x850 | 1000x1000 |
| MACHINE TONNAGE | 75 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 500 |
| RAM SIZE DIA (MM) | 220 MM | 250 MM | 300 MM | 350 MM | 400 MM | 450 MM | 500 MM | 550 MM | 600 MM |
| DAYLITE GAP | 500 MM | 500 MM | 500 MM | 400-500 MM | 400-500 MM | 400-500 MM | 400-500 MM | 500-800 MM | 500-900 MM |
| MAN MOTOR | 5 HP | 5 HP | 5 HP | 7.5 HP | 10 HP | 10 HP | 15 HP | 15 HP | 20 HP |
| MAIN RAM STROKE | 500 MM | 500 MM | 500 MM | 500 MM | 500 MM | 500 MM | 500 MM | 500 MM | 500 MM |
