Rubber Mixing Machines Archives

Showing all 2 results

Model		VAT(M) - 50/ 40	VAT(M) - 75/ 40	VAT(M) - 110/ 40	VAT(M) - 140/ 40	VAT(M) - 160/ 40	VAT(M) - 190/ 40	VAT(M) - 250/ 40	VAT(M) - 270/ 40
Total volume of mixing chamber (L)		50	75	110	140	160	190	250	270
Working volume of mixing chamber (L)		35	50	80	100	120	140	190	205
Speed of rear rotor (r/min)		40	40(6-60)	40(4-40)	40	40(6-60)	40(6-60)	20/40(4-40,6-60)	20/40(4-40,6-60)
Rotor speed ratio		1.167	1.185	1.156	1.15	1:1.143/1:1	1:1.143/1:1	1.2:1/1:1	1:1.7/1:1
Compressed air pressure (mpa)		0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Cooling water pressure (mpa)		0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4	0.3-0.4
Main motor power (KW)		75	160/315	220/400	315	355/500/750	800/1100	1120/1250/1500	1100/1250/1500
Overall dimension (mm)	(L)	5095	5600	5690	6525	6760	7000	7500	8690
	(W)	1950	2300	2745	2800	2900	3330	4305	4325
	(H)	3180	4600	4670	5280	5280	6200	5768	6140
Weight (T)		11	16..8	28	33	38	46	48.5	51

Model		VAT-250	VAT-300	VAT-360	VAT-400	VAT-450	VAT-550	VAT-610	VAT-660	VAT-660(R)	VAT-710	VAT-760	VAT-810
Diameter of rolls(mm)		250	300	360	400	450	550	610	660	660	710	760	810
Working length of rolls(mm)		620	760	900	1000	1200	1530	1830	2130	2130	2200	2540	2540
Linear speed of front roll(m/min)		15.2	14.5	16.26	18.65	23.85	27.18	28.7	32.45	28.6	31.9	33.23	31.9
Roll Friction Ratio		1:1.10	1:1.10	1:1.25	1:1.27	1:1.27	1:1.25	1:1.25	1:1.09	1:1.24	1:1.09	1:1.09	1:1.09
Batch Capacity		10-15	14-16	15-20	25-35	30-50	50-60	90-120	165	165	350	350	350
Motor Power		18.5	22	30	40	55	110	160	185	250	280	315	355
Max. Nip(mm)		8	8	10	10	10	15	15	15	15	15	15	15
Overall dimension(mm)	L	3220	3570	3920	4380	5050	6040	6750	7040	7465	7650	8560	8680
	W	1500	1400	1650	1710	1920	2100	3040	3660	3660	3200	2970	3575
	H	1290	1350	1725	1880	1870	1625	1743	2080	2080	2860	1970	3020
Weight(ton)		3.8	4.5	6	8	13	22	35	45	45	50	58	68
