Compression MoldingRubber milling process
Buy | Sell Used Rubber Cracker For Rubber Powder Making VAT – 450 mm
| Model | VAT-360 | VAT-400 | VAT-450 | VAT-550 | VAT-560 | VAT-660 | VAT-710 | |
| Diameter of rolls(mm) | 360 | 400 | 450 | 550 | 560-510 | 660 | 710 | |
| Working length of rolls(mm) | 900 | 1000 | 1200 | 1500 | 1530 | 2130 | 2200 | |
| Linear speed of front roll(r/min) | 16.25 | 18.65 | 21.8 | 22.5 | 27.2 | 28 | 31.9 | |
| Speed ratio of front & rear roll | 01:01.3 | 01:01.3 | 01:01.3 | 01:01.2 | 01:01.2 | 01:01.2 | 01:01.5 | |
| Max roll gap(mm) | 10 | 10 | 15 | 16 | 15 | 15 | 15 | |
| Feeding capacity per batch(kg) | 20-25 | 18-35 | 50 | 50-65 | 50-65 | 165 | 190 | |
| Driving motor power(kw) | 30 | 45 | 55 | 110 | 90 | 240 | 280 | |
| Bearing body structure | Roller bearing with grease/thin oil lubrication+square type reducer | |||||||
| Overall dimension(mm) | L | 4200 | 4920 | 5405 | 6646 | 6270 | 7280 | 8185 |
| W | 1780 | 1780 | 1740 | 2736 | 2282 | 3400 | 3910 | |
| H | 1760 | 1800 | 1790 | 2105 | 2000 | 2530 | 2270 | |
| Weight(ton) | 6.5 | 7.5 | 12 | 22 | 22.5 | 49 | 51 | |
Buy | Sell Used Tire Recycling Line Rubber Powder Production Line With 610 mm Cracker
| Model | VAT-360 | VAT-400 | VAT-450 | VAT-550 | VAT-560 | VAT-660 | VAT-710 | |
| Diameter of rolls(mm) | 360 | 400 | 450 | 550 | 560-510 | 660 | 710 | |
| Working length of rolls(mm) | 900 | 1000 | 1200 | 1500 | 1530 | 2130 | 2200 | |
| Linear speed of front roll(r/min) | 16.25 | 18.65 | 21.8 | 22.5 | 27.2 | 28 | 31.9 | |
| Speed ratio of front & rear roll | 01:01.3 | 01:01.3 | 01:01.3 | 01:01.2 | 01:01.2 | 01:01.2 | 01:01.5 | |
| Max roll gap(mm) | 10 | 10 | 15 | 16 | 15 | 15 | 15 | |
| Feeding capacity per batch(kg) | 20-25 | 18-35 | 50 | 50-65 | 50-65 | 165 | 190 | |
| Driving motor power(kW) | 30 | 45 | 55 | 110 | 90 | 240 | 280 | |
| Bearing body structure | Roller bearing with grease/thin oil lubrication+square type reducer | |||||||
| Overall dimension(mm) | L | 4200 | 4920 | 5405 | 6646 | 6270 | 7280 | 8185 |
| W | 1780 | 1780 | 1740 | 2736 | 2282 | 3400 | 3910 | |
| H | 1760 | 1800 | 1790 | 2105 | 2000 | 2530 | 2270 | |
| Weight(ton) | 6.5 | 7.5 | 12 | 22 | 22.5 | 49 | 51 | |
Buy | Sell Used Rubber Refiner Mill 450x510x1000 mm
| Working diameter of rolls(mm) | φ400front roller φ480rear roller | φ450front roller φ510rear roller | φ480front roller φ610rear roller |
| Roll casting process | centrifugal composite casting | centrifugal composite casting | centrifugal composite casting |
| Roll cooling mode | Around the borehole cooling | Around the borehole cooling | Around the borehole cooling |
| The surface of the roll material | High nickel chromium molybdenum alloy | High nickel chromium molybdenum alloy | High nickel chromium molybdenum alloy |
| Working length of the roll(mm) | 650 | 800/1000 | 800/1000/1200 |
| After the roller line speed(m/min) | 32.94(optional) | 49/55.2/63.4(optional) | 57.5-75.1(optional) |
| Front and rear roller line speed ratio | 1.27-1.815(optional) | 1.38/1.82/2(optional) | 1.27-1.815(optional) |
| Production capacity(kg/h) | 300 | 360 | 500-800 |
| Motor power(kw) | 55 | 55 | 75/90 |
| Roller spacing adjustment range(mm) | 0.1-15 | 0.1-15 | 0.1-15 |
| Reducer | ZSY hard-tooth face gear | ZSY hard-tooth face gear | ZSY hard-tooth face gear |
| Bearing type | the double spherical roller bearing | the double spherical roller bearing | the double spherical roller bearing |
| Dimensions of LxWxH(mm) | 4750x2300x1835 | 4060x2200x1470 | 5070x2800x1978 |
| Quality(kg） | about 10500 | about 12800 | about 20000 |
