Compression MoldingPre-Owned Rubber Machinery
88-Inch Tire Curing & Vulcanizing press for OTR & Tractor Tyres
| del | Bead Diameter | Applicable Tyre | Maximum Closing Force/Cavity (Tons) | Platen Diameter (mm) | Mould Accommodation Height | Max Tyre Internal Pressure kg/cm2 | |
| Max (mm) | Min (mm) | ||||||
| VAT 24” | 8" -12" | Scooter | 50 | 630 | 240 | 120 | 21 |
| VAT 30” | 8" - 12" | Scooter & Motorcycle | 70 | 805 | 250 | 120 | 21 |
| VAT 36” | 8" - 19" | Scooter & Motorcycle | 75 | 915 | 260 | 120 | 21 |
| VAT 42” | 16" - 19" | Passenger Cars & LCV | 140 | 1010 | 330 | 120 | 28 |
| VAT 45” | 17" - 19" | Passenger Cars & LCV | 160 | 1070 | 460 | 200 | 28 |
| Dome Presses (Truck) | |||||||
| VAT 55" | 15" - 22.5" | Bus & Truck | 295 | 1310 | 445 | 241 | 7 Kg/Cm2 |
| VAT 65.5" | 17" - 24.5" | Bus ,Truck & Tractor Rear | 453 | 1575 | 635 | 254 | 7 Kg/Cm2 |
Buy/Sell Secondhand Rubber Mixing Mill 26×84 (660×2130 mm)
| Model | VAT-250 | VAT-300 | VAT-360 | VAT-400 | VAT-450 | VAT-550 | VAT-610 | VAT-660 | VAT-660(R) | VAT-710 | VAT-760 | VAT-810 | |
| Diameter of rolls(mm) | 250 | 300 | 360 | 400 | 450 | 550 | 610 | 660 | 660 | 710 | 760 | 810 | |
| Working length of rolls(mm) | 620 | 760 | 900 | 1000 | 1200 | 1530 | 1830 | 2130 | 2130 | 2200 | 2540 | 2540 | |
| Linear speed of front roll(m/min) | 15.2 | 14.5 | 16.26 | 18.65 | 23.85 | 27.18 | 28.7 | 32.45 | 28.6 | 31.9 | 33.23 | 31.9 | |
| Roll Friction Ratio | 1:1.10 | 1:1.10 | 1:1.25 | 1:1.27 | 1:1.27 | 1:1.25 | 1:1.25 | 1:1.09 | 1:1.24 | 1:1.09 | 1:1.09 | 1:1.09 | |
| Batch Capacity | 10-15 | 14-16 | 15-20 | 25-35 | 30-50 | 50-60 | 90-120 | 165 | 165 | 350 | 350 | 350 | |
| Motor Power | 18.5 | 22 | 30 | 40 | 55 | 110 | 160 | 185 | 250 | 280 | 315 | 355 | |
| Max. Nip(mm) | 8 | 8 | 10 | 10 | 10 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | |
Overall dimension(mm) | L | 3220 | 3570 | 3920 | 4380 | 5050 | 6040 | 6750 | 7040 | 7465 | 7650 | 8560 | 8680 |
| W | 1500 | 1400 | 1650 | 1710 | 1920 | 2100 | 3040 | 3660 | 3660 | 3200 | 2970 | 3575 | |
| H | 1290 | 1350 | 1725 | 1880 | 1870 | 1625 | 1743 | 2080 | 2080 | 2860 | 1970 | 3020 | |
| Weight(ton) | 3.8 | 4.5 | 6 | 8 | 13 | 22 | 35 | 45 | 45 | 50 | 58 | 68 | |
Pre-Owned 400×1000 Rubber Mixing Mill – Excellent Condition
| Model | VAT-250 | VAT-300 | VAT-360 | VAT-400 | VAT-450 | VAT-550 | VAT-610 | VAT-660 | VAT-660(R) | VAT-710 | VAT-760 | VAT-810 | |
| Diameter of rolls(mm) | 250 | 300 | 360 | 400 | 450 | 550 | 610 | 660 | 660 | 710 | 760 | 810 | |
| Working length of rolls(mm) | 620 | 760 | 900 | 1000 | 1200 | 1530 | 1830 | 2130 | 2130 | 2200 | 2540 | 2540 | |
| Linear speed of front roll(m/min) | 15.2 | 14.5 | 16.26 | 18.65 | 23.85 | 27.18 | 28.7 | 32.45 | 28.6 | 31.9 | 33.23 | 31.9 | |
| Roll Friction Ratio | 1:1.10 | 1:1.10 | 1:1.25 | 1:1.27 | 1:1.27 | 1:1.25 | 1:1.25 | 1:1.09 | 1:1.24 | 1:1.09 | 1:1.09 | 1:1.09 | |
| Batch Capacity | 10-15 | 14-16 | 15-20 | 25-35 | 30-50 | 50-60 | 90-120 | 165 | 165 | 350 | 350 | 350 | |
| Motor Power | 18.5 | 22 | 30 | 40 | 55 | 110 | 160 | 185 | 250 | 280 | 315 | 355 | |
| Max. Nip(mm) | 8 | 8 | 10 | 10 | 10 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | |
Overall dimension(mm) | L | 3220 | 3570 | 3920 | 4380 | 5050 | 6040 | 6750 | 7040 | 7465 | 7650 | 8560 | 8680 |
| W | 1500 | 1400 | 1650 | 1710 | 1920 | 2100 | 3040 | 3660 | 3660 | 3200 | 2970 | 3575 | |
| H | 1290 | 1350 | 1725 | 1880 | 1870 | 1625 | 1743 | 2080 | 2080 | 2860 | 1970 | 3020 | |
| Weight(ton) | 3.8 | 4.5 | 6 | 8 | 13 | 22 | 35 | 45 | 45 | 50 | 58 | 68 | |
Pre-Owned Rubber Banbury Mixer 160 Ltr Hydraulic Type Machine
| Model | VAT-45E | VAT-90E | VAT-135E | VAT160E | VAT-190E | |||
| Total volume of mixing chamber (L) | 45 | 90 | 135 | 160 | 190 | |||
| Working volume of mixing chamber (L) | 30 | 56 | 90 | 104 | 125 | |||
| Speed of rear rotor (r/min) | 6-60 | 5-50 | 6-60 | 5-50 | 6-60 | |||
| Rotor speed ratio | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 | |||
| Compressed air pressure (mpa) | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | |||
| Cooling water pressure (mpa) | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | |||
| Main motor power (kw) | 280 | 450 | 720 | 750 | 1100 | |||
Overall dimension (mm) | (L) | 6200 | 7400 | 8200 | 8600 | 9000 | ||
| (W) | 2500 | 2880 | 2950 | 3000 | 4000 | |||
| (H) | 3750 | 4700 | 5375 | 6000 | 6220 | |||
| Weight (T) | 15 | 23 | 29 | 39 | 45 | |||
Reused Internal Mixer with Hydraulic Ram DXS 270 Make Dalian – 2013 Model
| Model | VAT(M) - 50/ 40 | VAT(M) - 75/ 40 | VAT(M) - 110/ 40 | VAT(M) - 140/ 40 | VAT(M) - 160/ 40 | VAT(M) - 190/ 40 | VAT(M) - 250/ 40 | VAT(M) - 270/ 40 | |
| Total volume of mixing chamber (L) | 50 | 75 | 110 | 140 | 160 | 190 | 250 | 270 | |
| Working volume of mixing chamber (L) | 35 | 50 | 80 | 100 | 120 | 140 | 190 | 205 | |
| Speed of rear rotor (r/min) | 40 | 40(6-60) | 40(4-40) | 40 | 40(6-60) | 40(6-60) | 20/40(4-40,6-60) | 20/40(4-40,6-60) | |
| Rotor speed ratio | 1.167 | 1.185 | 1.156 | 1.15 | 1:1.143/1:1 | 1:1.143/1:1 | 1.2:1/1:1 | 1:1.7/1:1 | |
| Compressed air pressure (mpa) | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | |
| Cooling water pressure (mpa) | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | |
| Main motor power (KW) | 75 | 160/315 | 220/400 | 315 | 355/500/750 | 800/1100 | 1120/1250/1500 | 1100/1250/1500 | |
Overall dimension (mm) | (L) | 5095 | 5600 | 5690 | 6525 | 6760 | 7000 | 7500 | 8690 |
| (W) | 1950 | 2300 | 2745 | 2800 | 2900 | 3330 | 4305 | 4325 | |
| (H) | 3180 | 4600 | 4670 | 5280 | 5280 | 6200 | 5768 | 6140 | |
| Weight (T) | 11 | 16..8 | 28 | 33 | 38 | 46 | 48.5 | 51 | |
