Compression MoldingTIRE-TUBE & TREAD BUILDING MACHINERY
Introducing our cutting-edge Tire-Tube and tread Machines, designed to revolutionize tire maintenance and retreading processes. Engineered with precision and efficiency in mind, these machines cater to the diverse needs of tire shops, automotive industries, and retreading facilities.
Buy | Sell Used Tire Curing Press 63.5 Inch Barometric
| Model | Bead Diameter | Applicable Tyre | Maximum Closing Force/Cavity (Tons) | Platen Diameter (mm) | Mould Accommodation Height | Max Tyre Internal Pressure kg/cm2 | |
| Max (mm) | Min (mm) | ||||||
| VAT 24” | 8" -12" | Scooter | 50 | 630 | 240 | 120 | 21 |
| VAT 30” | 8" - 12" | Scooter & Motorcycle | 70 | 805 | 250 | 120 | 21 |
| VAT 36” | 8" - 19" | Scooter & Motorcycle | 75 | 915 | 260 | 120 | 21 |
| VAT 42” | 16" - 19" | Passenger Cars & LCV | 140 | 1010 | 330 | 120 | 28 |
| VAT 45” | 17" - 19" | Passenger Cars & LCV | 160 | 1070 | 460 | 200 | 28 |
| Dome Presses (Truck) | |||||||
| VAT 55" | 15" - 22.5" | Bus & Truck | 295 | 1310 | 445 | 241 | 7 Kg/Cm2 |
| VAT 65.5" | 17" - 24.5" | Bus ,Truck & Tractor Rear | 453 | 1575 | 635 | 254 | 7 Kg/Cm2 |
Buy | Sell Used Tractor Tire Curing Press 65” Make Guilin China
a-sheets-root="1"><col width="145" />h="166" /></p><table class="yoast-text-mark" dir="ltr" border="1" cellspacing="0" cellpadding="0">-sheets-value="{"1":2,"2":"Model"}">Modeldata-sheets-value="{"1":2,"2":"Bead Diameter"}">Bead DiameterApplicable TyreMaximum Closing Force/Cavity (Tons)Platen Diameter (mm)Mold Accommodation HeightMax Tyre Internal Pressure kg/cm2olspan="5" rowspan="1"> Max (mm)Min (mm)
VAT 24”8" -12"Scooter5063024012021VAT 30”8" - 12"Scooter & Motorcycle70ot;:3,"3":805}">805250alue="{"1":3,"3":120}">12021VAT 36”8" - 19"Scooter & Motorcycle7591526012021VAT 42”16" - 19"Passenger Cars & LCV140101033012028VAT 45”17" - 19"Passenger Cars & LCV160107046020028Dome Presses (Truck)VAT 55"15" - 22.5"Bus & Truck29513104452417 Kg/Cm2VAT 65.5"17" - 24.5"Bus, Truck & Tractor Rear45315756352547 Kg/Cm2
Buy | Sell Used Truck Tire Making 55 inch Bagomatic Curing Press
| Model | Bead Diameter | Applicable Tyre | Maximum Closing Force/Cavity (Tons) | Platen Diameter (mm) | Mold Accommodation Height | Max Tyre Internal Pressure kg/cm2 | |
| Max (mm) | Min (mm) | ||||||
| VAT 24” | 8" -12" | Scooter | 50 | 630 | 240 | 120 | 21 |
| VAT 30” | 8" - 12" | Scooter & Motorcycle | 70 | 805 | 250 | 120 | 21 |
| VAT 36” | 8" - 19" | Scooter & Motorcycle | 75 | 915 | 260 | 120 | 21 |
| VAT 42” | 16" - 19" | Passenger Cars & LCV | 140 | 1010 | 330 | 120 | 28 |
| VAT 45” | 17" - 19" | Passenger Cars & LCV | 160 | 1070 | 460 | 200 | 28 |
| Dome Presses (Truck) | |||||||
| VAT 55" | 15" - 22.5" | Bus & Truck | 295 | 1310 | 445 | 241 | 7 Kg/Cm2 |
| VAT 65.5" | 17" - 24.5" | Bus, Truck & Tractor Rear | 453 | 1575 | 635 | 254 | 7 Kg/Cm2 |
Buy | Sell Secondhand Rubber Tire Curing Machine 600 Tons
| Model | Bead Diameter | Applicable Tyre | Maximum Closing Force/Cavity (Tons) | Platen Diameter (mm) | Mold Accommodation Height | Max Tyre Internal Pressure kg/cm2 | |
| Max (mm) | Min (mm) | ||||||
| VAT 24” | 8" -12" | Scooter | 50 | 630 | 240 | 120 | 21 |
| VAT 30” | 8" - 12" | Scooter & Motorcycle | 70 | 805 | 250 | 120 | 21 |
| VAT 36” | 8" - 19" | Scooter & Motorcycle | 75 | 915 | 260 | 120 | 21 |
| VAT 42” | 16" - 19" | Passenger Cars & LCV | 140 | 1010 | 330 | 120 | 28 |
| VAT 45” | 17" - 19" | Passenger Cars & LCV | 160 | 1070 | 460 | 200 | 28 |
| Dome Presses (Truck) | |||||||
| VAT 55" | 15" - 22.5" | Bus & Truck | 295 | 1310 | 445 | 241 | 7 Kg/Cm2 |
| VAT 65.5" | 17" - 24.5" | Bus , Truck & Tractor Rear | 453 | 1575 | 635 | 254 | 7 Kg/Cm2 |
Buy | Sell Used Inner Tire Buty l Tube Manufacturing Machinery
| Type | LLN-25/2 Double-layer |
| Specification | 28 |
| Max. mold clamping force (KN) | 255 |
| Max. O.D. of heating plate (mm) | 760 |
| Suitable mold height (mm) | 70-120 |
| Time interval from open to close mold (s) | 4.2 |
| Motor power (kw/h) | 5.5 |
| Steam pressure of plate (Mpa) | 0.8 |
| The internal pressure of the machine (Mpa) | 1 |
| Weight (KG) | 1600 |
| Overall dim. (mm) | 1280 X 900X 1770 |
Buy | Sell Used Passenger Tire Production Line Machines
| Model | Bead Diameter | Applicable Tyre | Maximum Closing Force/Cavity (Tons) | Platen Diameter (mm) | Mold Accommodation Height | Max Tyre Internal Pressure kg/cm2 | |
| Max (mm) | Min (mm) | ||||||
| VAT 24” | 8" -12" | Scooter | 50 | 630 | 240 | 120 | 21 |
| VAT 30” | 8" - 12" | Scooter & Motorcycle | 70 | 805 | 250 | 120 | 21 |
| VAT 36” | 8" - 19" | Scooter & Motorcycle | 75 | 915 | 260 | 120 | 21 |
| VAT 42” | 16" - 19" | Passenger Cars & LCV | 140 | 1010 | 330 | 120 | 28 |
| VAT 45” | 17" - 19" | Passenger Cars & LCV | 160 | 1070 | 460 | 200 | 28 |
| Dome Presses (Truck) | |||||||
| VAT 55" | 15" - 22.5" | Bus & Truck | 295 | 1310 | 445 | 241 | 7 Kg/Cm2 |
| VAT 65.5" | 17" - 24.5" | Bus,Truck & Tractor Rear | 453 | 1575 | 635 | 254 | 7 Kg/Cm2 |
Buy | Sell Used Tyre Precured Tread Building Hydraulic Press
| Models | VAT-360 | VAT-650 | VAT-800 | VAT-1000 | VAT-1200 | VAT-2000 |
| Clamping Force (T) | 360 | 650 | 800 | 1000 | 1200 | 2000 |
| Table Size (mm) | 305×3650 | 305×8000 | 400×8000 | 350×5500 | 625×4500 | 400×11000 |
| Daylight (mm) | 125each | 125each | 125each | 125each | 150each | 150each |
| No. of Daylight / Layers | 4 Nos. | 5 Nos. | 5 Nos. | 4 Nos. | 6 Nos. | 5 Nos. |
| Stroke of the Main Cylinder | 500mm | 600mm | 550mm | 500mm | 900mm | 750mm |
| No. of Cylinders | 5 Nos. | 12Nos. | 8Nos. | 10Nos. | 8Nos. | 20Nos. |
| Stroke of the Main Cylinder | Ø200mm | Ø200mm | Ø250mm | Ø250mm | Ø300mm | Ø250mm |
| Electric Motor (H.P.) | 10 H.P. | 20 H.P. | 25 H.P. | 25 H.P. | 30 H.P. | 40 H.P. |
| Working Pressure (Bar) | 200 Bar | 200 Bar | 200 Bar | 200 Bar | 200 Bar | 200 Bar |
Used 350mm Inner Tube Jointing/Splicer Machine – Fabo Mech
| Model | VAT- 900 | VAT- 1100 | VAT- 1200 |
| Tube Flat Width Maximum | 200 mm | 500 mm | 750 mm |
| Tube Flat Width Minimum | 20 mm | 120 mm | 450 mm |
| Double Thickness Standard Special | 20 mm max./28 mm | 20 mm max./28 mm | 20 mm max./28 mm |
| Maximum Unspliced Tube Length Standard Special | 800 mm/650 mm | 800 mm/650 mm | 1200 mm |
| Machine Height (Approx) | 1900 mm | 1900 mm | 2300 mm |
| Machine Width (Approx) | 1600 mm | 1600 mm | 2100 mm |
| Machine Depth (Approx) | 1600 mm | 1600 mm | 1700 mm |
| Nett Weight (Approx) | 2500 kgs | 2500 kgs | 5000 kgs |
| Tubes Per Cycle | Two | One | One |
| Approximate Machine Cycle Time | 25-40 Seconds | 20-35 Seconds | 30-55 Seconds |
| Electrical Supply | 6.5 kW at 415V, 3 Phase, 50 Hertz |
